Arduino Adjustable 3-80cm E18-D80NK IR Infrared Range Sensor Switch (autosumo/sumo robot) Robotic

  • Sale
  • RM11.00 MYR
  • 3 available

Photoelectric sensor (photoelectric switch) NPN normally open

 Model: E18-D50NK


 Photoelectric switch E18 technical parameters :



 1, the output current DC / SCR / Relay Control output: 200mA/5V powered

 2, the DC current consumption <30mA

 3, response time <2ms

 4, point angle: ? 15 °, effective distance 3-80CM adjustable

 5, detection of objects: transparent or opaque body

 6, the working environment temperature: -25 °C ~ 55 °C


 7, the standard sensing object: sunlight 10000LX The following incandescent 3000LX

 8, Case Material: Plastic
